Range Hood - Slat Flat

Introducing our fully parametric Hood!

Tired of showing your customers a Sketchup model or an incomplete range hood? This file allows you to show your clients exactly the ballast hood you are providing them!

Hinge the front MDF panel (attach slats to this panel) to give fully access to the ducting and blower. Required in most municipalities for building code.

Slat width and number of slats on front face can be quickly modified and part spacing quickly calculated and duplicated on the side of the hood.

This file includes all the necessary user parameters for the following:

• 1. Hood Shape
• 2. Add Bottom trim?
• 4. Cutout Size for Blower
• 5. Cutout Size for Vent Pipe
• 6. Adjustment of Slat Width, Spacing and QTY

REQUIRED TOOLING:

1. 3/8 Compression (Cutout Tool)
2. 5mm Drill or 3mm Drill (User Parameter)
